Kurzweil PC2 [151/170] Pc2 programs and controller assignments
![Kurzweil PC2 [151/170] Pc2 programs and controller assignments](/views2/2008899/page151/bg97.png)
PC2 Programs and Controller Assignments
Programs and Controllers
C-9
ID 49
Program Name Ballad Of 3 Bars
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Perc XFade
Slider D Bass Cut
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW3 VAST Chr/Vib On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
ID 50
Program Name Prog Rocker's B
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Perc XFade
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
ID 51
Program Name All Out Full On
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
ID 52
Program Name Grungy Overdrive
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW3 VAST Chr/Vib On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
ID 53
Program Name Uptown Gospel
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Para EQ Freq
Slider D Para EQ Cut
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
ID 54
Program Name Retro Roto
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Xtra Hi Freq
SW1 Octave Shift
SW2 FX Vib/Chr On/Off
SW3 VAST Chr/Vib On/Off
SW4 Arp On/Off
SW5 VAST Rotary On/Off
MW FX/VAST Rotary Ramp Speed Ctl
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 FX/VAST Rotary Ramp Speed Ctl
