![Kurzweil PC2 [136/170] Flange](/views2/2008899/page136/bg88.png)
B-14
Reference
PC2 Effects and Effects Parameters
Flange
Phase
Chorus + Delay
200Ð233 can be combined to create Chorus/Delay/Reverb multi-effects
ID Effect Param1 Param2 Param3 Param4
150 Big Slow Flange LFO Period LFO TempoFdbk Level L/R Phase
151 Sweet Flange LFO Period LFO Tempo Fdbk Level L/R Phase
152 Throaty Flange LFO Period LFO Tempo HF Damping
153 Squeeze Flange LFO Period LFO Tempo Fdbk Level L/R Phase
154 Simply Flange LFO Period LFO Tempo Fdbk Level L/R Phase
155 Wetlip Flange LFO Period Fdbk Level StatDlyLvl StatDlyTim
ID Effect Param1 Param2 Param3 Param4
180 Slow Deep Phaser LFO Rate LFO Depth CenterFreq L/R Phase
181 Saucepan Phaser LFO Rate LFO Depth CenterFreq Fdbk Level
182 Circles LFO Rate LFO Depth NotchLFORt NotchDepth
ID Effect Param1 Param2 Param3 Param4
200 BasicChorusDelay Mix Chorus
Ch FdbkMix DelayDly
Tempo
201 Doubler & Echo Ch Depth L Ch Depth R Mix Delay Dly Tempo
202 FastChorusDouble Mix Chorus Ch Rate L Ch Rate R Mix Delay
203 Chorus Slapbacks Mix Chorus Mix Delay Dly TempoDly LFDamp
204 Chorus PanDelay Mix Chorus Ch Fdbk Mix DelayDly Tempo
205 Chorused Taps 4 Tap Tempo 4Tap Fdbk Tap1 Delay Tap3 Delay
206 MultiEchoChorus Ch Rate L Ch Rate R Dly Time LDly Time R
