PC2 Programs and Controller Assignments
Programs and Controllers
C-3
ID 13
Program Name Ragtime Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped
ID 14
Program Name Tack Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Tack Level
Slider D Vibrato Rate
SW1 Octave Shift
SW4 Arp On/Off
SW5 Enable Vibrato
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 15
Program Name Piano & Strings
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C LoPass Freq
Slider D Strings Level
SW1 Octave Shift
SW2 Enable Vibrato
SW4 Arp On/Off
SW5 Lyr Disable (Strings)
MW Vibrato Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 soft ped-pno
ID 16
Program Name Classic E Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Sample Start
SW4 Arp On/Off
SW5 Impact
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Bass Boost
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
ID 17
Program Name serious classic
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider D Tremolo Rate
SW1 Octave Shift
SW4 Arp On/Off
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 18
Program Name Stage E Piano
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Tremolo Rate
SW1 Octave Shift
SW2 Enable Thump
SW4 Arp On/Off
SW5 Impact
MW Tremolo Depth
Ribbon Pitch Bend
CCPed1 Expression
CCPed2 Timbre
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Soft Pedal
