C-18
PC2 Programs and Controller Assignments
Programs and Controllers
ID 114
Program Name Ambient Rock Kit
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Decay Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Sample Start
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 115
Program Name Coliseum Kit
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Decay Control
SW3 Pitch Drop
SW4 Arp On/Off
SW5 Sample Start
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 116
Program Name Resonant Traps
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Envelope Control
SW3 Pitch Up
SW4 Arp On/Off
SW5 Sample Start
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 117
Program Name Tripkit/Trashkit
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Envelope Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Sample Start
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
ID 118
Program Name Beat Box
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Decay Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Sample Start
MW "Env/Lyr, Ptch LFO"
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Lyr Enable/Pitch LFO
ID 119
Program Name Electro Kit
Slider A FX-A Wet/Dry
Slider B FX-B Wet/Dry
Slider C Timbre
Slider D Pitch Control
SW1 Octave Shift
SW2 Decay Control
SW3 Layer Switch
SW4 Arp On/Off
SW5 Attack Control
MW Layer Enable
Ribbon Pitch Bend
CCPed1 Expression
FtSw1 Sustain
FtSw2 Sostenuto
FtSw3 Layer Enable
