Kurzweil PC2 [123/170] Voltage and frequency ranges
![Kurzweil PC2 [123/170] Voltage and frequency ranges](/views2/2008899/page123/bg7b.png)
Reference
Specifications
B-1
Appendix B
Reference
Specifications
SpeciÞcations are subject to change without notice.
Physical Specifications
Electrical Specifications
Voltage and Frequency Ranges
Power Consumption
Dimension PC2 PC2X
Height
4
5
/
16
in
10.95 cm
4
5
/
16
in
10.95 cm
Depth 14 in 35.60 cm 14 in 35.60 cm
Length
47
13
/
16
in
121.45 cm
54
5
/
16
in
137.95 cm
Weight 35 lb 16 kg 50 lb 23 kg
120 VAC
Adapter Model PM0023A
230 VAC
(Adapter Model PM0024A
Safe voltage range 100–125 Volts RMS 200–230 Volts RMS
Safe frequency range 58–65 Hz 48–65 Hz
Voltage Level Power consumption
120 VAC 0.6 Amps
230 VAC 0.3 Amps
