ASUS MAXIMUS VIII RANGER

3-27

Chapter 3

Graphics Configuration

Allows you to select a primary display from graphical devices.

Primary Display [Auto]

[Auto] The primary display will be set to PCI-E when a PCI-E graphic

card is detected.

[IGFX] Force the primary display to be from the IGFX Graphics.

[PEG] Force the primary display to be from the PEG Graphics.

[PCIE] Force the primary display to be from the PCI-E graphic cards.

iGPU Multi-Monitor [Disabled]

Set this to enabled to empower both integrated and discrete graphics for multi-monitor

output.

Conguration options: [Enabled] [Disabled]

DMI/OPI Configuration

Allows you to congure the DMI/OPI settings.

DMI Max Link Speed [Auto]

Conguration options: [Auto] [Gen1] [Gen2] [Gen3]

PEG Port Configuration

Allows you to congure the PEG Port settings.

PCIEX16/X8_1

PCIEX16/X8_1 Link Speed [Auto]

Allows you to select the operating speed of the PCIEX16/X8_1 speed.

Conguration options:

[Auto] The system will automatically select the PCIEX16/X8_1 slot speed.

[Gen1] The PCIEX16/X8_1 slot will run at PCI-E 1.0 speed.

[Gen2] The PCIEX16/X8_1 slot will run at PCI-E 2.0 speed.

[Gen3] The PCIEX16/X8_1 slot will run at PCI-E 3.0 speed.

PCIEX8_2

PCIEX8_2 Link Speed [Auto]

Allows you to select the operating speed of the PCIEX8_2 speed.

Conguration options:

[Auto] The system will automatically select the PCIEX16/X8_1 slot speed.

[Gen1] The PCIEX8_2 slot will run at PCI-E 1.0 speed.

[Gen2] The PCIEX8_2 slot will run at PCI-E 2.0 speed.

[Gen3] The PCIEX8_2 slot will run at PCI-E 3.0 speed.
