ASUS MAXIMUS VIII RANGER
1-15
Chapter 1
DDR4 2666 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
2 4
CORSAIR CMD16GX4M4A2666C15
(Ver4.23) (XMP)
16GB ( 4x
4GB )
SS - - 15-17-17-35 1.2 • •
CORSAIR CMD16GX4M4A2666C16
(Ver4.23 )(XMP)
16GB ( 4x
4GB )
SS - - 16-18-18-35 1.2 • •
CORSAIR CMD16GX4M4A2666C16
(Ver5.29) (XMP)
16GB ( 4x
4GB )
SS - - 16-18-18-35 1.2 • •
CORSAIR CMK16GX4M4A2666C15
(Ver4.23) (XMP)
16GB ( 4x
4GB )
SS - - 15-17-17-35 1.2 • •
CORSAIR CMK16GX4M4A2666C15
(Ver5.29)
16GB ( 4x
4GB )
SS - - 15-17-17-35 1.2 • •
CORSAIR CMK16GX4M4A2666C16
(Ver4.23) (XMP)
16GB ( 4x
4GB )
SS - - 16-18-18-35 1.2 • •
CORSAIR CMK16GX4M4A2666C16
(Ver5.29 )(XMP)
16GB ( 4x
4GB )
SS - - 16-18-18-35 1.2 • •
CORSAIR CMD128GX4M8A2666C15
(Ver4.31) (XMP)
128GB
(16x
8GB )
DS - - 15-17-17-35 1.2 • •
CORSAIR CMD128GX4M8A2666C15
(Ver4.31) (XMP)
128GB
(16x
8GB )
DS - - 15-17-17-35 1.2
CORSAIR CMD32GX4M4A2666C15
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 15-17-17-35 1.2 • •
CORSAIR CMD32GX4M4A2666C15
(Ver5.29)
32GB ( 4x
8GB )
DS - - 15-17-17-35 1.2 • •
CORSAIR CMD32GX4M4A2666C16
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 16-18-18-35 1.2 • •
CORSAIR CMK32GX4M4A2666C15
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 15-17-17-35 1.2 • •
CORSAIR CMK32GX4M4A2666C15
(Ver5.29) (XMP)
32GB ( 4x
8GB )
DS - - 15-17-17-35 1.2 • •
CORSAIR CMK32GX4M4A2666C16
(Ver5.29) (XMP)
32GB ( 4x
8GB )
DS - - 16-16-18-35 1.2 • •
CORSAIR CMK32GX4M4A2666C16R
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 16-18-18-35 1.2 • •
G.SKILL F4-2666C15Q-16GRR
(XMP)
16GB ( 4x
4GB )
SS - - 15-15-15-35 1.2 • •
G.SKILL F4-2666C15Q-32GRR
(XMP)
32GB ( 4x
8GB )
DS - - 15-15-15-35 1.2 • •
G.SKILL F4-2666C16Q2-64GRB
(XMP)
64GB ( 8x
8GB )
DS - - 16-16-16-36 1.2 • •
AVEXIR AVD4U26661504G-4CIR
(XMP)
4GB SS - - 15-15-15-35 1.2 • •
AVEXIR AVD4U26661608G-4CIR
(XMP)
32GB ( 8x
4GB )
DS - - 16-16-16-36 1.2 • •
ISDT IMA451U6MFR8N-CF0
(XMP)
4GB SS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • •
ISDT IMA41GU6MFR8N-CF0
(XMP)
8GB DS ISDT I5AN4G8NMFR 15-15-15-35 1.2 • •
Team TCD44G2666C15ABK
(XMP)
4GB SS Samsung K4A4G085WD 15-15-15-35 1.2 • •
Team TCD48G2666C15ABK
(XMP)
32GB(4x
8GB)
DS Team TCD48G2666C15ABK 15-15-15-35 1.2 • •
