3-30
Chapter 3: BIOS Setup
Chapter 3
The following item appears only when you set the SATA Mode Selection to [RAID].
M.2 PCIE Storage RAID Support [Disabled]
This item allows you to enable or disable PCIE port to SATA for RAID Remapping.
Conguration options: [Disabled] [Enabled]
SATA Express 1 PCIE Storage RAID Support [Disabled]
This item allows you to enable or disable PCIE port to SATA for RAID Remapping.
Conguration options: [Disabled] [Enabled]
SATA Express 2 PCIE Storage RAID Support [Disabled]
This item allows you to enable or disable PCIE port to SATA for RAID Remapping.
Conguration options: [Disabled] [Enabled]
SMART Self Test [On]
Run SMART Self Test on all HDDs during POST.
Conguration options: [On] [Off]
Aggressive LPM Support [Disabled]
This item is designed for LPM (link power management) support with a better energy saving
conditions. When set to [Enabled], the hot plug function of SATA ports are disabled.
Conguration options: [Disabled] [Enabled]
SATA6G_1(Gray) - SATA6G_6(Gray)
SATA6G_1(Gray) - SATA6G_6(Gray) [Enabled]
This item allows you to enable or disable the selected SATA port.
Conguration options: [Disabled] [Enabled]
Hot Plug [Disabled]
These items appears only when the SATA Mode Selection is set to [AHCI] and allows
you to enable or disable SATA Hot Plug Support.
Conguration options: [Disabled] [Enabled]
