![Asus rog maximus viii ranger [68/200] Front i o connector](/img/pdf.png)
Asus rog maximus viii ranger [68/200] Front i o connector
![Asus rog maximus viii ranger [68/200] Front i o connector](/views2/1162355/page68/bg44.png)
2-10
Chapter 2: Basic Installation
Chapter 2
2.1.7 Front I/O Connector
To install ASUS Q-Connector
USB 2.0
AAFP
To install USB 2.0 connector To install front panel audio connector
USB 3.0
To install USB 3.0 connector
