MAXIMUS VIII RANGER Motherboard Qualified Vendors Lists (QVL)
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
2 4
G.SKILL F4-3333C16D-8GTZ 8GB(4GB*2) SS SK hynix H5AN4G8NMFR 16-18-18-38 1.35V •
G.SKILL F4-3333C16Q-16GRKD 16GB(4GB*4) SS Samsung K4A4G085WD 16-16-16-36 1.35V •
CORSAIR CMD16GX4M4B3333C16
ver4.23
16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-36 1.35V •
A-DATA AX4U3333W4G16 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 16-16-16-36 1.35V •
DDR4 3333 MHz capability
DDR4 3300 MHz capability
DDR4 3400 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
2 4
CORSAIR CMD16GX4M4B3400C16
ver. 4.23
16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-38 1.35V • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
2 4
G.SKILL F4-3300C16Q-16GRK 16GB(4GB*4) SS SK hynix H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3300C16D-8GTZ 8GB(4GB*2) SS Samsung K4A4G085WD 16-18-18-38 1.35V • •
CORSAIR CMD16GX4M4B3300C16 16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-36 1.35V •
