ASUS MAXIMUS VIII RANGER

3-19

Chapter 3

BCLK Frequency Slew Rate

This item allows you to set frequency update rate. Lower values speed up clock

changes.

Conguration options: [Auto] [Disable] [32us/MHz] [64us/MHz] [128us/MHz] [512us/

MHz]

DRAM VTT Voltage [Auto]

Conguration options: [Auto] [0.50000] - [1.30000]

VPPDDR Voltage [Auto]

Conguration options: [Auto] [1.86500] - [3.13500]

DMI Voltage [Auto]

Conguration options: [Auto] [0.30000] - [1.90000]

Core PLL Voltage [Auto]

Conguration options: [Auto] [0.70000] - [2.10000]

PLL Bandwidth [Auto]

Select Level 6 to Level 8 when overclocking High BCLK or High CPU frequency.

Conguration options: [Auto] [Level 0] - [Level 10]

Eventual DRAM Voltage [Auto]

Conguration options: [Auto] [1.0032] - [2.0064]

Eventual CPU Standby Voltage [Auto]

Conguration options: [Auto] [0.800] - [1.800]

CPU Core/Cache Current Limit Max. [Auto]

This item allows you to congure a higher current limit to prevent a frequency or power

throttling when overclocking. Use the <+> and <-> keys to adjust the value.

Conguration options: [Auto] [0.00] - [255.50]

CPU Graphics Current Limit Max. [Auto]

This item allows you to congure a higher current limit to prevent a frequency or power

throttling when overclocking. Use the <+> and <-> keys to adjust the value.

Conguration options: [Auto] [0.00] - [255.50]

Min. CPU Cache Ratio [Auto]

This item allows you to set the minimum possible CPU cache ratio. Use the <+> and <-> keys

to adjust the value.

Conguration options: [Auto] [8] - [33]

Max. CPU Cache Ratio [Auto]

This item allows you to set the maximum possible CPU cache ratio. Use the <+> and <->

keys to adjust the value.

Conguration options: [Auto] [8] - [33]

Max. CPU Graphics Ratio [Auto]

This item allows you to set the CPU graphics ratio. Use the <+> and <-> keys to adjust the

value.

Conguration options: [Auto] [8] - [33]
