ROG Exclusive Features
Start button
Reset button
Clear CMOS button
LN2 Mode
ROG RAMDisk
ROG RAMCache
Overwolf
KeyBot II
- One-click overclocking
- X.M.P.
- DirectKey
- Clr CMOS
- Power On
UEFI BIOS features :
- Extreme Tweaker
- Tweakers’ Paradise
- ROG SSD Secure Erase
- GPU.DIMM Post
- O.C. Prole
- Graphics Card Information Preview
Special Features
ASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU,
DIGI+ Power Control, Fan Xpert 3, and Turbo App
ASUS Exclusive Features
- AI Suite 3
- USB 3.1 Boost
- AI Charger+
- Push Notice
- Disk Unlocker
- PC Cleaner
- HyStream
- Media Streamer
- Mobo Connect
ASUS EZ DIY
- USB BIOS Flashback
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS C.P.R.(CPU Parameter Recall)
- MemOK!
MAXIMUS VIII RANGER specifications summary
