Chapter 1: Product Introduction
Chapter 1
DDR4 2400 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM
socket
support
(Optional)
2 4
CORSAIR CMD16GX4M4A2400C14
(Ver4.23) (XMP)
16GB ( 4x
4GB )
SS - - 14-16-16-31 1.2 • •
CORSAIR CMK16GX4M4A2400C14
(Ver4.23) (XMP)
16GB ( 4x
4GB )
SS - - 14-16-16-31 1.2 • •
CORSAIR CMD32GX4M4A2400C14
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 14-16-16-31 1.2 • •
CORSAIR CMK32GX4M4A2400C14
(Ver4.23) (XMP)
32GB ( 4x
8GB )
DS - - 14-16-16-31 1.2 • •
Crucial BLS4G4D240FSA.8FAD 4GB SS - - 16-16-16-40 1.2 • •
crucial BLS4G4D240FSA.8FAR
(XMP)
4GB SS - - 17-16-16-
39-2
1.2 • •
Crucial BLS8G4D240FSA.16FAD 8GB DS - - 16-16-16-40 1.2 • •
crucial BLS8G4D240FSA.16FAR
(XMP)
8GB DS - - 17-16-16-
39-2
1.2 • •
G.SKILL F4-2400C15Q-16GRR 16GB ( 4x
4GB )
SS - - 15-15-15-35 1.2 • •
G.SKILL F4-2400C15Q2-128GRK
(XMP)
128GB ( 8x
16GB )
DS - - 2400-15-15-
15-35
1.2 • •
G.SKILL F4-2400C15Q-32GRR 32GB ( 4x
8GB )
DS - - 15-15-15-35 1.2 • •
Kingston HX424C12PB2K4/16 16GB ( 4x
4GB )
SS - - 15-15-15-36 1.2 • •
AVEXIR AVD4U24001604G-4CIR
(XMP)
4GB SS - - 16-16-16-36 1.2 • •
AVEXIR AVD4U24001608G-4M
(XMP)
32GB ( 8x
4GB )
DS SK Hynix H5AN4G8NMFRTFC 16-16-16-36 1.2 • •
AVEXIR AVD4U24001608G-4M 32GB ( 8x
4GB )
DS SK Hynix H5AN4G8NMFRTFC 16-16-16-39 1.2 • •
Panram PUD42400C154G4NJW 16GB ( 4x
4GB )
SS - - 2400-15-15-
15-35
1.2 • •
Panram PUD42400C158G4NJW 32GB ( 4x
8GB )
DS - - 2400-15-15-
15-35
1.2 • •
Team TED44GM2400C16BK 4GB SS Samsung K4A4G085WD 16-16-16-39 1.2 • •
Team TED48GM2400C16BK 8GB DS Samsung K4A4G085WD 16-16-16-39 1.2 • •
V-color TD4G8C17-UH 4GB SS V-color DW3J0460HM 2400-15-15-
15-36
1.2 • •
