xii
Special Features
ASUS Q-Design
- Q-Code
- Q-Shield
- Q-Connector
- Q-LED (CPU, DRAM, VGA, Boot Device LED)
- Q-Slot
- Q-DIMM
Internal I/O Ports
2 x USB 3.0 headers support additional 4 USB 3.0 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports [one
connector via ROG_EXT header]
2 x SATA Express connectors
6 x SATA 6Gb/s connectors (4 ports from 2 x SATA Express)
1 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 storage
devices support (Supports PCIE 3.0 x4 and SATA modes)
1 x ROG extension (ROG_EXT) header
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU_OPT fan connector
4 x 4-Pin Chassis fan connectors
1 x 4-Pin Water pump connector
1 x EXT_Fan header
1 x Thermal sensor connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x Start button
1 x Reset button
1 x LN2 mode jumper
1 x MemOK! button
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX II series
support
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x System panel connector
BIOS
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM3.0,
SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ
Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan
Control, F3 My Favorites, F9 Quick Note, Last Modied log,
F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD
(Serial Presence Detect) memory information.
Manageability
WfM2.0, DMI3.0, WOL by PME, PXE
MAXIMUS VIII RANGER specifications summary
(continued on the next page)
