CPU Graphics Voltage Mode [Auto]

Congures the mode of Voltage fed to the CPU graphics.

Conguration options: [Auto] [Manual Mode] [Offset Mode]

The following items appear only when you set the CPU Graphics Voltage Mode to [Manual

Mode].

CPU Graphics Voltage Override [Auto]

Allows you to congure the CPU Graphics Voltage.

Conguration options: [Auto] [0.600] - [1.700]

The following items appear only when you set the CPU Graphics Voltage Mode to [Offset

Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Graphics Voltage Offset [Auto]

This item allows you to congure the CPU core voltage offset value.

Conguration options: [Auto] [0.001] - [0.635]

PCH Core Voltage [Auto]

Conguration options: [Auto] [0.70000] - [1.80000]

CPU Standby Voltage [Auto]

Conguration options: [Auto] [0.80000] - [1.80000]

DRAM REF Voltage Control

DRAM CTRL REF Voltage on CHA/CHB [Auto]

Congures the DRAM reference voltage on the control lines. The reference voltage will

be the DRAM voltage times the congured value.

Conguration options: [Auto] [0.39500] - [0.63000]

DRAM DATA REF Voltage on CHA/CHB DIMM0/1 Rank0/1 BL0-7 [Auto]

Congures the DRAM Data REF Voltage.

Conguration options: [Auto] [0] - [63]
