Chapter 3: BIOS Setup

Chapter 3

CPU Core/Cache Voltage [Auto]

Congures the mode of Voltage fed to the cores of the processor.

Conguration options: [Auto] [Manual Mode] [Offset Mode] [Adaptive Mode]

The following items appear only when you set the CPU Core/Cache Voltage to [Manual

Mode].

CPU Core Voltage Override [Auto]

Allows you to congure the CPU Core voltage.

Conguration options: [Auto] [0.600] - [1.700]

The following items appear only when you set the CPU Core/Cache Voltage to [Offset

Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Core Voltage Offset [Auto]

This item allows you to congure the CPU core voltage offset value.

Conguration options: [Auto] [0.005] - [0.635]

The following items appear only when you set the CPU Core/Cache Voltage to [Adaptive

Mode].

Offset Mode Sign [-]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

Additional Turbo Mode CPU Core Voltage [0.250]

This item allows you to congure the CPU core voltage offset value.

Conguration options: [0.250] - [1.920]

Offset Voltage [Auto]

This item allows you to congure the CPU core voltage offset value.

Conguration options: [Auto] [0.001] - [0.999]

DRAM Voltage [Auto]

Conguration options: [Auto] [1.0032] - [2.0064]

CPU VCCIO Voltage [Auto]

Conguration options: [Auto] [0.70000] - [1.80000]

CPU System Agent Voltage [Auto]

Conguration options: [Auto] [0.70000] - [1.80000]
