Lenovo B50-30/B50-30 Touch/B50-45/B50-70
29
Thesystemstatusindicatorsbelowshowthecomputerstatus:
Table2.Statusindicators
Indicator Status Meaning
Powerand
battery
status
indicator
Green
• Thebatteryhasachargebetween20%and100%
andtheACadapterisnotconnectedtothe
computer.
• Thebatteryhasachargebetween80%and100%
andtheACpoweradapterisconnectedtothe
computer.
Blinking
Green
• Thebatteryhasachargebetween20%and80%
andtheACpoweradapterisconnectedtothe
computer.
• Thecomputerisinsleepmode.
Amber
Thebatteryhasachargebetween5%and20%and
theACadapterisnotconnectedtothecomputer.
Blinking
amber
Thebatteryhasachargeof20%orlessandtheAC
poweradapterisconnectedtothecomputer.
Off
• Thebatteryisdetached.
• Thebatteryhasachargeof5%orlessandtheAC
adapterisnotconnectedtothecomputer.
• Thecomputerispoweredofforinhibernate
mode.
Harddisk
drive
indicator
On Theharddiskdriveisreadingorwritingdata.
Status indicators
1
2
a
b
