Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
64
Figure20.RemovalstepsofAntenna,LCDcable,andintegratedcamera
ReleasetwoantennacablesandoneLCDcablefromthecableguide.Detachthe
adhesiveoftheantennatoremovetheminthedirectionbyarrow .
When installing:
• Routetheantennacablesalongthecableguidesandsecuretheantenna
boardswithadhesivetapes.Asyouroutethecables,makesurethattheyare
notsubjectedtoanytension.Tensioncancausethecablestobedamagedby
thecableguides,orawiretobebroken.
• Makesurethatthecameraconnectorisattachedfirmly.
c
2
3
3
