Lenovo B50-30/B50-30 Touch/B50-45/B50-70
53
1140 Fan and heat sink assembly
Foraccess,removetheseFRUsinorder:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1040Harddiskdrive”onpage37
• “1050DIMM”onpage39
• “1060PCIExpressMiniCardforwirelessLAN/WAN”onpage40
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
• “1110Ledboard”onpage48
• “1130Systemboard”onpage50
Figure14.Removalstepsoffanandheatsinkassembly
Disconnectthefanconnectorinthedirectionbyarrow .Removethescrew
andsixscrews .Thenremovethefanandheatsinkinthedirectionasshown
byarrow .
When installing:MakesurethatallthefanandDC‐INconnectorsareattached
firmly.
Step Screw (quantity) Color Torque
M2x5mm,flat‐head,nylok‐coated(1) Silver 1.5~2.0kgf.cm
M2x3mm,flat‐head,nylok‐coated(6) Black 1.0~1.5kgf.cm
a
b
c
d
3
3
3
3
3
2
1
4
7
db
7
dc
