Lenovo B50-30/B50-30 Touch/B50-45/B50-70
49
1120 Docking board (on select models)
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
Figure12.Removalstepsofdockingboard
Disconnecttwoconnectorsinthedirectionbyarrow .Removetwoscrews
.Thenremovethedockingboardinthedirectionbyarrow .
Wheninstalling:Makesurethatthetwoconnectorsareattachedfirmly.
Step Screw (quantity) Color Torque
M2.5x4mm,flat‐head,nylok‐coated(2) Black 2.0~2.5kgf.cm
a
b
c
d
1
2
3
4
c
