Lenovo B50-30/B50-30 Touch/B50-45/B50-70
57
ForWindows7operatingSystem:
Note: Applying labels to the base cover
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveral
kinds.Whenyoureplacethebasecover,youneedtoapplythefollowing
labels:
Thefollowinglabelsneedtobepeeledofffromtheoldbasecover,andput
onthenewbasecover.
PalmRestLabel
ESlabel
VGAlabel
CPUlabel
Win7C‐Sticker
Ratinglabel
Ratingprintlabel
WLAN&BTLabel
Indonesiaratinglabel
COAlabel
Forsomemodels,youalsoneedtoapplyoneortwoFCClabels.Checkthe
oldbasecover;ifithasoneortwoFCClabels,findduplicatesoftheminthe
labelkitandapplythemtothenewbasecover.
Forthelocationofeachlabel,refertothefollowingfigure:
B50‐30/B50‐30Touch/B50‐45/B50‐70:
2
1
a
b
c
d
e
f
g
h
i
Notes:
NoWLAN&BTLabel(h)case,aligntheIndonesiaratinglabel(i)tothe
WLAN&BTlabel(h).
