Lenovo b50-30, 59-426189 [49/88] Finger print and power board
![Lenovo b50-30, 59-426189 [49/88] Finger print and power board](/views2/1172275/page49/bg31.png)
Lenovo B50-30/B50-30 Touch/B50-45/B50-70
45
1090 Finger print and power board
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
Figure9.Removalstepsoffingerprintandpowerboard
Disconnectthefingerprintconnectinthedirectionbyarrow .Remove
thescrew .Removethefingerprintbracketinthedirectionbyarrow .
Thenremovethefingerprintbyarrow .
Step Screw (quantity) Color Torque
M2x3mm,flat‐head,nylok‐coated(1) Black 1.0~1.5kgf.cm
a
b
c
d
d
4
3
1
2
b
