Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
46
Figure9.Removalstepsoffingerprintandpowerboard(Continued)
PeelofftheadhesiveofthepowerboardFPC.Removethescrew .Then
removethepowerboardinthedirectionbyarrow .
When installing:Makesurethatthefingerprintconnectorisattachedfirmly.
Step Screw (quantity) Color Torque
M2x3mm,flat‐head,nylok‐coated(1) Black 1.0~1.5kgf.cm
e
f
5
6
b
