Lenovo B50-30/B50-30 Touch/B50-45/B50-70
41
1070 Keyboard
Foraccess,removethisFRU:
• “1010Batterypack”onpage33
Figure7.Removalstepsofkeyboard
Removethreescrews .
Pulltounsnapthekeyboardinthedirectionbyarrows .
Step Screw (quantity) Color Torque
M2x6mm,flat‐head,nylok‐coated(3) Black 1.5~2.0kgf.cm
a
1
1
1
a
b
c
2
2
3
