Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
38
Figure4.Removalstepsofharddiskdrive(continued)
Removefourscrews anddetachtheharddiskdrivefromthemetalframein
thedirectionshownbyarrow .
When installing:MakesurethattheHDDconnectorisattachedfirmly.
Step Screw (quantity) Color Torque
M3x3mm,flat‐head,nylok‐coated(4) Silver 2.5~3.0kgf.cm
ec
ed
3
3
4
3
3
e
c
