Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
70
Table5.Partslist—Overall
No. FRU FRU no. CRU
ID
1 LCDunit(see“LCDFRUs”onpage73)
2 Keyboard(see“Keyboard”onpage75)
3 Batterypack,4cell,14.4V41Wh,SYL12S4E55 121500239 *
3 Batterypack,4cell,14.8V41Wh,LGL12L4E55 121500241 *
3 Batterypack,4cell,14.88V41Wh,SP/LL12M4E55 121500240 *
3 Batterypack,4cell,14.4V32Wh,SYL13S4A01 121500242 *
3 Batterypack,4cell,14.4V32Wh,LGL13L4A01 121500244 *
3 Batterypack,4cell,14.4V32Wh,SP/LL13M4A01 121500243 *
4 ZIWB3PowerBoardW/Cable 90007354 N
5 ZIWB3UpperCaseW/TPWO/FP 90205519 N
5 ZIWB3UpperCaseW/FP/TP 90205520 N
6 ZIWB2FingerprintBoardWorldfair 90007268 N
7 ZIWB2Fan 90205424 N
8 ZIWB3SpeakerW/RubberL+R 90205528 N
9 ZIWB0HeatSinkUMA 90205512 N
9 ZIWB1HeatSinkDIS 90205551 N
9 ZIWB3HeatSinkDIS 90205526 N
9 ZIWB3HeatSinkUMA 90205527 N
9 CB50‐45DIS 5H40F86188 N
9 CB50‐45UMA 5H40F86210 N
10 ZIWB3BatteryBoard 90007357 N
11 ZIWB3LEDBoardW/Cable 90007353 N
12 ODD,9.0mmTray‐inRambo,HLDSGUA0N 25215010 *
12 ODD,9.0mmTray‐inRambo,PLDSDA‐8A5SH 25213110 *
12 ODD,9.0mmTray‐inRambo,QSIUJ8FBS 25215312 *
12 ODD,9.0mmTray‐inRambo,TSSTSU‐228FB 25215832 *
13 ZIWB3ODDBezel 90205516 *
14 ZIWB3ODDBoard 90007355 N
15 ZIWB1MBN15V1GN28151000W/FP 90007430 N
15 ZIWB1MBW8PN15V1GN28151000W/FP 90007431 N
15 ZIWB1MBW8SN15V1GN2815 1000W/FP 90007432 N
15 ZIWB1MBUMAN29201000WO/FP 90007433 N
15 ZIWB1MBW8PUMAN29201000WO/FP 90007434 N
15 ZIWB1MBW8SUMAN29201000WO/FP 90007435 N
15 ZIWB1MBUMAN35201000WO/FP 90007436 N
15 ZIWB1MBW8PUMAN35201000WO/FP 90007437 N
15 ZIWB1MBW8SUMAN35201000WO/FP 9 0007438 N
15 ZIWB3MBJet‐LE2GI7‐4500U1000W/FP 90007358 N
15 ZIWB3MBW8PJet‐LE2GI7‐4500U1000W/FP 90007359 N
15 ZIWB3MBW8SJet‐LE2GI7‐4500U1000W/FP 90007360 N
15 ZIWB3MBJet‐LE2GI5‐4200U1000W/FP 90007361 N
15 ZIWB3MBW8PJet‐LE2GI5‐4200U1000W/FP 90007362 N
15 ZIWB3MBW8SJet‐LE2GI5‐4200U1000W/FP 90007363 N
15 ZIWB3MBI5‐4200UUMA 1000WO/FP 90007364 N
15 ZIWB3MBW8PI5‐4200UUMA1000WO/FP 90007365 N
