Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
74
Table6.Partslist—15.6‐in.HDTFT
No. FRU FRUno. CRU
ID
1 ZIWB3LCDBezelW/C am eraHole/Magnet/Mylar 90205535 N
1 ZIWB3LCDBezelWO/CameraHole/Magnet/Mylar 90205536 N
1 ZIWB1LCDBezelW/MagnetTS 90205553 N
2 ZIWB1LCDModule3.8H HDTS 90400300 N
2 ZIWB1LCDModule3.2H FHDTS 90400301 N
3 ZIWB3HingeL+RNT 90205531 N
3 ZIWB1HingeL+RTS 90205554 N
4 ZIWB1AntennaMain+AUXTS 90205555 N
4 ZIWB3AntennaMain+AUXNT 90205532 N
5 ZIWB2CameraBoard1MW/MylarTS 90007315 N
5 ZIWB2CameraBoard0.3MW/MylarTS 90007316 N
5 ZIWB2CameraBoard1MNT 90007266 N
5 ZIWB2CameraBoard0.3MNT 90007267 N
6 ZIWB3LCDCableWO/CameraCableNT 90205533 N
6 ZIWB3LCDCableW/CameraCableNT 90205533 N
6 ZIWB1LCDCableW/CameraCableTS 90205556 N
7 ZIWB3LCDCoverNT 90205537 N
7 ZIWB1LCDCoverTS 90205557 N
