Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
62
1190 LCD hinges
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1040Harddiskdrive”onpage37
• “1050DIMM”onpage39
• “1060PCIExpressMiniCardforwirelessLAN/WAN”onpage40
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
• “1110Ledboard”onpage48
• “1130Systemboard”onpage50
• “1160LCDunitandbasecover”onpage55
• “1170LCDfrontbezel”onpage59
• “1180LCDpanel”onpage60
Figure19.Removalstepsofhinges
Removetwoscrews andsixscrews .Removethehingesinthedirection
shownbyarrow .
Step Screw (quantity) Color Torque
M2x4mm,flat‐head,nylok‐coated(2) Black 1.5~2.0kgf.cm
M2.5x4mm,flat‐head,nylok‐coated(6) Black 2.0~2.5kgf.cm
a
b
c
2
2
2
1
3
2
1
3
a
a
b
