Lenovo B50-30/B50-30 Touch/B50-45/B50-70
33
1010 Battery pack
Figure1.Removalstepsofbatterypack
Unlockthemanualbatterylatch .Whileholdingthespring‐loadedbattery
latchintheunlockedposition ,thenremovethebatterypackinthedirection
shownbyarrow .
When installing:Installthebatterypackalongthesliderailsoftheslot.Then
makesurethemanualbatterylatchinthelockposition.
DANGER
•Onlyusethebatteryspecifiedinthepartslistforyourcomputer.Any
otherbatterycouldigniteorexplode.
a
b
c
2
2
3
1
1
