Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
36
1030 Bottom slot cover
Foraccess,removethisFRU:
“1010Batterypack”onpage33
Figure3.Removalstepsofbottomslotcover
Removethetwoscrews .Thenremovethebottomslotcoverbyarrow .
Step Screw (quantity) Color Torque
M2.5x5mm,flat‐head,nylok‐coated(2) Black 2.0~2.5kgf.cm
a
b
1
2
1
a
