Lenovo B50-30/B50-30 Touch/B50-45/B50-70
77
Table7.Partslist—Keyboard(continued)
Language P/N CRUID
Chicony
English 25214725 **
U.K.English 25214726
Italian 25214727
Spanish 25214728
Turkish 25214729
Thailand 25214730
Portugue 25214731
Latin 25214732
CanadaEnglish&French 25214733
Korean 25214734
TradationalChinese 25214735
Russian 25214736
French 25214737
German 25214738
Arabic 25214739
Brazilian 25214740
Dutch 25214742
Greek 25214743
Hebrew 25214744
Hungarian 25214745
Nordic 25214746
Belgian 2 5214747
Iceland 25214748
Slovenian 25214749
Swiss 25214750
InternationalEnglish 25214751
Czechoslovakian 25214752
Bulgarian 25214753
India 25214754
