1130 System board
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1040Harddiskdrive”onpage37
• “1050DIMM”onpage39
• “1060PCIExpressMiniCardforwirelessLAN/WAN”onpage40
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
• “1110Ledboard”onpage48
Figure13.Removalstepsofsystemboard
Disconnectthespeakerconnectorinthedirectionbyarrow .
Important notices for handling the system board:
Whenhandlingthesystemboard,bearthefollowinginmind.
• Becarefulnottodropthesystemboardonabenchtopthathasahard
surface,suchasmetal,wood,orcomposite.
• Avoidroughhandlingofanykind.
• Inthewholeprocess,makesurenottodroporstackthesystemboard.
• Ifyouputasystemboarddown,makesuretoputitonlyonapadded
surfacesuchasanESDmatorconductivecorrugatedmaterial.
a
1
