Lenovo B50-30/B50-30 Touch/B50-45/ B50-70
Hardware Maintenance Manual
54
1150 Speakers and battery board
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1040Harddiskdrive”onpage37
• “1050DIMM”onpage39
• “1060PCIExpressMiniCardforwirelessLAN/WAN”onpage40
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
• “1110Ledboard”onpage48
• “1130Systemboard”onpage50
Figure15.Removalstepsofspeakersandbatteryboard
Removetwoscrews andfourscrews .Removethespeakersandthe
batteryboardinthedirectionbyarrow .
When installing:Routethespeakerscablesalongthecableguides.
Step Screw (quantity) Color Torque
M2.5x4mm,flat‐head,nylok‐coated(2) Black 2.0~2.5kgf.cm
M2x2mm,flat‐head,nylok‐coated(4) Black 1.0~1.5kgf.cm
a
b
c
2
2
2
2
1
3
3
3
7
d
a
7
db
