Lenovo B50-30/B50-30 Touch/B50-45/B50-70
55
1160 LCD unit and base cover
Foraccess,removetheseFRUs:
• “1010Batterypack”onpage33
• “1020Opticaldrive”onpage34
• “1030Bottomslotcover”onpage36
• “1040Harddiskdrive”onpage37
• “1050DIMM”onpage39
• “1060PCIExpressMiniCardforwirelessLAN/WAN”onpage40
• “1070Keyboard”onpage41
• “1080Keyboardbezel”onpage43
• “1100USBboardandODDboard”onpage47
• “1110Ledboard”onpage48
• “1120Dockingboard(onselectmodels)”onpage49
• “1130Systemboard”onpage50
Figure16.RemovalstepsofLCDunitandbasecover
Releasethetwoantennacablesfromthecableguidesbyarrows.Removesix
screws .
Step Screw (quantity) Color Torque
M2.5x4mm,flat‐head,nylok‐coated(6) Black 2.0~2.5kgf.cm
b
a
1
1
1
1
b
a
