ioLogik E4200 Using Modbus/TCP
B-2
System Configuration Map Addresses
3xxxx Read only Registers (Support function 4)
System information
Reference Address Data Type Description
324577 0x6000 1 word Reserved
324578 0x6001 1 word Unit ID (Ethernet=1)
324579 0x6002 1 word Product Code=0x4200
324580 0x6003 to 0x6016 20 word Reserved
324600 0x6017 to 0x602A 20 word Product name string=“E4200 Active Ethernet
Network Adaptor”
324620 0x602B to 0x602C 2 word Product serial number (decimal)
324622 0x602D to 0x602E 2 word Firmware revision:
Word 0 Hi byte = major (A)
Word 0 Lo byte = minor (B)
Word 1 Hi byte = release (C)
Word 1 Lo byte = build (D)
format is A.B.C.D
324624 0x602F to 0x6030 2 word Firmware release date
High word = 0x2006
Low word = 0x1101
firmware release date is Nov. 1, 2006
324626 0x6031 1 word Number of TCP connected
324627 0x6032 1 word Ethernet Interface-0 speed, 0x10(10Mbps) or
0x100(100Mbps)
324628 0x6033 1 word Ethernet Interface-1 speed, 0x10(10Mbps) or
0x100(100Mbps)
324629 0x6034 3 word Ethernet Interface-0 MAC
324632 0x6037 3 word Ethernet Interface-1 MAC
324635 0x603A 1 word Reserved
324636 0x603B 1 word Reserved
324637 0x603C 1 word Reserved
324638 0x603D to 0x603E 2 word System Elapsed Time (in sec)
324640 0x603F 1 word Modbus/RTU Unit ID=1
324641 0x6040 to 0x6041 2 word Reserved
324643 0x6042 1 word Reserved
324644 0x6043to0x6062 32 word Reserved
324676 0x6063 1 word Reserved
324677 0x6064 1 word Number of attached modules
324678 0x6065 1 word Reserved
324679 0x6066 1 word Reserved
324680 0x6067 1 word LEDs status
Low-byte:SYS-LED
High-byte:IO-LED
bit0:OFF0x01
bit1:Green0x02
bit2:Red0x04
bit3:Flashing Green0x08
bit4:Flashing Red0x10
bit5:Green&Read0x20(reserved)
324681 0x6068 1 word Reserved
