ioLogik E4200 Using Modbus/TCP
B-5
Word 0 Hi byte = 192
Word 0 Lo byte = 168
Word 1 Hi byte = 15
Word 1 Lo byte = 1
Time Server Address is “192.168.15.1”
424761 0x60B8 to 0x60CB 20 word Log server
424781 0x60CC 1 word Log server port
424782 0x60CD to 0x60EA 30 word Adaptor location
424812 0x60EB to 0x6108 30 word Adaptor name
424842 0x6109 1 word Reserved
424843 0x610A 1 word Modbus addressing mode
0:Fixed mode
1:Dynamic mode
424844 0x610B to 0x611A 16 word Reserved
424860 0x611B 1 word Reserved
424861 0x611C to 0x611D 2 word Reserved
424863 0x611E 1 word Reserved
424864 0x611F 1 word Reserved
424865 0x6120 to 0x6184 101 word Reserved
424966 0x6185 to 0x6194 16 word Reserved
432769 0x8000 1 word Reserved
432850 0x8051 to 0x8058 8 word Logic & Go Name
434422 0x8675 1 word Internal Register 00 Value (Power On)
434423 0x8676 1 word Internal Register 01 Value (Power On)
434424 0x8677 1 word Internal Register 02 Value (Power On)
434425 0x8678 1 word Internal Register 03 Value (Power On)
434426 0x8679 1 word Internal Register 04 Value (Power On)
434427 0x867A 1 word Internal Register 05 Value (Power On)
434428 0x867B 1 word Internal Register 06 Value (Power On)
434429 0x867C 1 word Internal Register 07 Value (Power On)
434430 0x867D 1 word Internal Register 08 Value (Power On)
434431 0x867E 1 word Internal Register 09 Value (Power On)
434432 0x867F 1 word Internal Register 10 Value (Power On)
434433 0x8680 1 word Internal Register 11 Value (Power On)
434434 0x8681 1 word Internal Register 12 Value (Power On)
434435 0x8682 1 word Internal Register 13 Value (Power On)
434436 0x8683 1 word Internal Register 14 Value (Power On)
434437 0x8684 1 word Internal Register 15 Value (Power On)
434438 0x8685 1 word Internal Register 16 Value (Power On)
434439 0x8686 1 word Internal Register 17 Value (Power On)
434440 0x8687 1 word Internal Register 18 Value (Power On)
434441 0x8688 1 word Internal Register 19 Value (Power On)
434442 0x8689 1 word Internal Register 20 Value (Power On)
434443 0x868A 1 word Internal Register 21 Value (Power On)
434444 0x868B 1 word Internal Register 22 Value (Power On)
434445 0x868C 1 word Internal Register 23 Value (Power On)
434446 0x868D 1 word Internal Register 24 Value (Power On)
434447 0x868E 1 word Internal Register 25 Value (Power On)
434448 0x868F 1 word Internal Register 26 Value (Power On)
434449 0x8690 1 word Internal Register 27 Value (Power On)
434450 0x8691 1 word Internal Register 28 Value (Power On)
434451 0x8692 1 word Internal Register 29 Value (Power On)
434452 0x8693 1 word Internal Register 30 Value (Power On)
