ioLogik E4200 Using Modbus/TCP
B-7
434949 0x8884 1 word Internal Register 04 Value (Working)
434950 0x8885 1 word Internal Register 05 Value (Working)
434951 0x8886 1 word Internal Register 06 Value (Working)
434952 0x8887 1 word Internal Register 07 Value (Working)
434953 0x8888 1 word Internal Register 08 Value (Working)
434954 0x8889 1 word Internal Register 09 Value (Working)
434955 0x888A 1 word Internal Register 10 Value (Working)
434956 0x888B 1 word Internal Register 11 Value (Working)
434957 0x888C 1 word Internal Register 12 Value (Working)
434958 0x888D 1 word Internal Register 13 Value (Working)
434959 0x888E 1 word Internal Register 14 Value (Working)
434960 0x888F 1 word Internal Register 15 Value (Working)
434961 0x8890 1 word Internal Register 16 Value (Working)
434962 0x8891 1 word Internal Register 17 Value (Working)
434963 0x8892 1 word Internal Register 18 Value (Working)
434964 0x8893 1 word Internal Register 19 Value (Working)
434965 0x8894 1 word Internal Register 20 Value (Working)
434966 0x8895 1 word Internal Register 21 Value (Working)
434967 0x8896 1 word Internal Register 22 Value (Working)
434968 0x8897 1 word Internal Register 23 Value (Working)
434969 0x8898 1 word Internal Register 24 Value (Working)
434970 0x8899 1 word Internal Register 25 Value (Working)
434971 0x889A 1 word Internal Register 26 Value (Working)
434972 0x889B 1 word Internal Register 27 Value (Working)
434973 0x889C 1 word Internal Register 28 Value (Working)
434974 0x889D 1 word Internal Register 29 Value (Working)
434975 0x889E 1 word Internal Register 30 Value (Working)
434976 0x889F 1 word Internal Register 31 Value (Working)
434977 0x88A0 1 word Internal Register 32 Value (Working)
434978 0x88A1 1 word Internal Register 33 Value (Working)
434979 0x88A2 1 word Internal Register 34 Value (Working)
434980 0x88A3 1 word Internal Register 35 Value (Working)
434981 0x88A4 1 word Internal Register 36 Value (Working)
434982 0x88A5 1 word Internal Register 37 Value (Working)
434983 0x88A6 1 word Internal Register 38 Value (Working)
434984 0x88A7 1 word Internal Register 39 Value (Working)
434985 0x88A8 1 word Internal Register 40 Value (Working)
434986 0x88A9 1 word Internal Register 41 Value (Working)
434987 0x88AA 1 word Internal Register 42 Value (Working)
434988 0x88AB 1 word Internal Register 43 Value (Working)
434989 0x88AC 1 word Internal Register 44 Value (Working)
434990 0x88AD 1 word Internal Register 45 Value (Working)
434991 0x88AE 1 word Internal Register 46 Value (Working)
434992 0x88AF 1 word Internal Register 47 Value (Working)
434993 0x88B0 1 word Internal Register 48 Value (Working)
434994 0x88B1 1 word Internal Register 49 Value (Working)
434995 0x88B2 1 word Internal Register 50 Value (Working)
434996 0x88B3 1 word Internal Register 51 Value (Working)
434997 0x88B4 1 word Internal Register 52 Value (Working)
434998 0x88B5 1 word Internal Register 53 Value (Working)
434999 0x88B6 1 word Internal Register 54 Value (Working)
435000 0x88B7 1 word Internal Register 55 Value (Working)
435001 0x88B8 1 word Internal Register 56 Value (Working)
