ioLogik E4200 Using Modbus/TCP
B-6
434453 0x8694 1 word Internal Register 31 Value (Power On)
434454 0x8695 1 word Internal Register 32 Value (Power On)
434455 0x8696 1 word Internal Register 33 Value (Power On)
434456 0x8697 1 word Internal Register 34 Value (Power On)
434457 0x8698 1 word Internal Register 35 Value (Power On)
434458 0x8699 1 word Internal Register 36 Value (Power On)
434459 0x869A 1 word Internal Register 37 Value (Power On)
434460 0x869B 1 word Internal Register 38 Value (Power On)
434461 0x869C 1 word Internal Register 39 Value (Power On)
434462 0x869D 1 word Internal Register 40 Value (Power On)
434463 0x869E 1 word Internal Register 41 Value (Power On)
434464 0x869F 1 word Internal Register 42 Value (Power On)
434465 0x86A0 1 word Internal Register 43 Value (Power On)
434466 0x86A1 1 word Internal Register 44 Value (Power On)
434467 0x86A2 1 word Internal Register 45 Value (Power On)
434468 0x86A3 1 word Internal Register 46 Value (Power On)
434469 0x86A4 1 word Internal Register 47 Value (Power On)
434470 0x86A5 1 word Internal Register 48 Value (Power On)
434471 0x86A6 1 word Internal Register 49 Value (Power On)
434472 0x86A7 1 word Internal Register 50 Value (Power On)
434473 0x86A8 1 word Internal Register 51 Value (Power On)
434474 0x86A9 1 word Internal Register 52 Value (Power On)
434475 0x86AA 1 word Internal Register 53 Value (Power On)
434476 0x86AB 1 word Internal Register 54 Value (Power On)
434477 0x86AC 1 word Internal Register 55 Value (Power On)
434478 0x86AD 1 word Internal Register 56 Value (Power On)
434479 0x86AE 1 word Internal Register 57 Value (Power On)
434480 0x86AF 1 word Internal Register 58 Value (Power On)
434481 0x86B0 1 word Internal Register 59 Value (Power On)
434482 0x86B1 1 word Internal Register 60 Value (Power On)
434483 0x86B2 1 word Internal Register 61 Value (Power On)
434484 0x86B3 1 word Internal Register 62 Value (Power On)
434485 0x86B4 1 word Internal Register 63 Value (Power On)
434486 0x86B5 1 word Internal Register 64 Value (Power On)
434487 0x86B6 1 word Internal Register 65 Value (Power On)
434488 0x86B7 1 word Internal Register 66 Value (Power On)
434489 0x86B8 1 word Internal Register 67 Value (Power On)
434490 0x86B9 1 word Internal Register 68 Value (Power On)
434491 0x86BA 1 word Internal Register 69 Value (Power On)
434492 0x86BB 1 word Internal Register 70 Value (Power On)
434493 0x86BC 1 word Internal Register 71 Value (Power On)
434494 0x86BD 1 word Internal Register 72 Value (Power On)
434495 0x86BE 1 word Internal Register 73 Value (Power On)
434496 0x86BF 1 word Internal Register 74 Value (Power On)
434497 0x86C0 1 word Internal Register 75 Value (Power On)
434498 0x86C1 1 word Internal Register 76 Value (Power On)
434499 0x86C2 1 word Internal Register 77 Value (Power On)
434500 0x86C3 1 word Internal Register 78 Value (Power On)
434501 0x86C4 1 word Internal Register 79 Value (Power On)
434945 0x8880 1 word Internal Register 00 Value (Working)
434946 0x8881 1 word Internal Register 01 Value (Working)
434947 0x8882 1 word Internal Register 02 Value (Working)
434948 0x8883 1 word Internal Register 03 Value (Working)
