ioLogik E4200 Using Modbus/TCP
B-4
Word 0 Hi byte = 192
Word 0 Lo byte = 168
Word 1 Hi byte = 15
Word 1 Lo byte = 1
Geteway is “192.168.15.1”
424587 0x600A to 0x600B 2 word LAN-1 Geteway (need reboot)
Word 0 Hi byte = 192
Word 0 Lo byte = 168
Word 1 Hi byte = 15
Word 1 Lo byte = 1
Geteway is “192.168.15.1”
424589 0x600C 1 word LAN-0 IP Acquisition mode
424590 0x600D 1 word LAN-1 IP Acquisition mode
424591 0x600E to 0x6011 4 word DNS Server 1/ Server 2 IP Address
Word 0 Hi byte = 192
Word 0 Lo byte = 168
Word 1 Hi byte = 15
Word 1 Lo byte = 1
Word 2 Hi byte = 192
Word 2 Lo byte = 168
Word 3 Hi byte = 15
Word 3 Lo byte = 2
DNS Server 1 IP Address is “192.168.15.1”
DNS Server 2 IP Address is “192.168.15.2”
424595 0x6012 1 word Timeout for idle TCP/IP connection
In sec
424596 0x6013 to 0x6018 6 word System Local Time:
Word 0= Sec: 00-59
Word 1= Min: 00-59
Word 2= Hour: 00-23
Word 3= Day: 01-31
Word 4= Month: 01-12
Word 5= Year: 2000-2099
424602 0x6019 1 word System Local Time zone (1 to 63), refer to appendix
time zone code.
424603 0x601A to 0x601F 6 word Reserved
424609 0x6020 1 word Enable/disable web access
Enable=1, disable=0
424610 0x6021 to 0x6034 20 word Reserved
424630 0x6035 5 word Reserved
424635 0x603A 1 word Host connection loss Time Out value
(enter safe state)
424636 0x603B 1 word Host connection loss Time Out flag
(enter safe state)
424637 0x603C 1 word SNMP Enable
424638 0x603D to 0x6046 10 word SNMP community
424648 0x6047 to 0x605A 20 word SNMP Contact
424669 0x605C to 0x606F 20 word SNMP Location
424690 0x6071 1 word Reserved
424691 0x6072 to 0x607B 10 word Reserved
424701 0x607C to 0x608F 20 word Reserved
424721 0x6090 to 0x60A3 20 word IP Allow Mask List
424741 0x60A4 to 0x60A5 2 word System Time Server Address
