F
F. Factory Default Settings
The ioLogik E4200 is configured with the following default private IP addresses:
LAN-0 Default IP address: 192.168.127.254
LAN-0 Default Netmask: 255.255.255.0
LAN-0 Default Gateway: 0.0.0.0 (None)
LAN-1 Default IP address: 192.168.126.254
LAN-1 Default Netmask: 255.255.255.0
LAN-1 Default Gateway: 0.0.0.0 (None)
IP Filter: Disable
Time Zone 23 (Greenwich)
Time server: None
Communication watchdog Disable
Watchdog Timeout: 60 secs
Password: empty
Module Name: empty
Module Location: empty
Web Console: Enable
SNMP: Enable
Read Community: “public”
Write Community: “private”
Contact: empty
Location: empty
Modbus Addressing Mode: Fixed mode
Click&Go Power-on Status: Stop
DO Power-on Status: Off
AO Power-on Status: 0x0000
TC Power-on sensor type: K-Type
TC Power-on CJC: Enable
RTD Power-on sensor type: PT100
TC/RTD Power-on Temperature Type: Celsius
DO Safe Action: Fault value
DO Fault value: Off
AO Safe Action: Fault value
AO Fault value: 0x0000
Alias name of DO: “DO”
Alias name of DI: “DI”
Alias name of AO: “AO”
Alias name of AI: “AI”
Alias name of TC: “TC”
Alias name of RTD: “RTD”
