Asus rs740-e7/rs24-eg [102/212] Allow 2x refresh enabled
![Asus rs740-e7/rs24-eg [102/212] Allow 2x refresh enabled](/views2/1214370/page102/bg66.png)
5-16
Chapter 5: BIOS setup
Data Scrambling [Enabled]
Allows you to enable/disable data scrambling.
Conguration options: [Enabled] [Disabled]
Device Tagging [Disabled]
Allows you to enable/disable device tagging.
Conguration options: [Enabled] [Disabled]
Thermal Throtting [CLTT]
Conguration options: [Disabled] [OLTT] [CLTT]
Enable High Temp [Disabled]
Conguration options: [Disabled] [Enabled]
Allow 2x Refresh [Enabled]
Conguration options: [Disabled] [Enabled]
Altitude [300 M]
The system altitude above the sea level in meters.
Conguration options: [Auto] [300 M] [900 M] [1500 M] [3000 M]
Memory Hot sensor support [Disbled]
Conguration options: [Disabled] [Enabled]
DIMM Information
CPU1 DIMM Information
Node 0 Ch0 Dimm A1 Present 2048 MB(DDR3)
Node 0 Ch0 Dimm A2 Not Present
Node 0 Ch1 Dimm B1 Not Present
Node 0 Ch1 Dimm B2 Not Present
Node 0 Ch2 Dimm C1 Not Present
Node 0 Ch2 Dimm C2 Not Present
Node 0 Ch3 Dimm D1 Not Present
Node 0 Ch3 Dimm D2 Not Present
CPU2 DIMM Information
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
