Asus rs740-e7/rs24-eg [22/212] Hdd status leds

Chapter 1: Product introduction

1-10

(Front) HDD LEDs status

SSD LED Description

GREEN The installed SSD is in good condition

OFF SSD failure or no SSD is installed

1.7.2 HDD status LEDs

HDD LED Description

GREEN The installed HDD is in good condition

OFF SSD failure or no HDD is installed

HDD status LED

(Rear) SSD status LEDs status

SSD status LED
