ASUS RS740-E7-RS24-EG
5-7
5.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Main For changing the basic system conguration
Advanced For changing the advanced system settings
Server Mgmt For changing the Server Mgmt settings
Event Logs For changing the event log settings
Monitor For displaying the system temperature, power status, and changing
the fan settings
Security For changing the security settings
Boot For changing the system boot conguration
Tool For conguring options for special functions
Exit For selecting the exit options
To select an item on the menu bar, press the right or left arrow key on the keyboard until the
desired item is highlighted.
5.2.1 BIOS menu screen
Navigation keys
General help
Menu bar CongurationeldsMenu items
