7-32 Chapter 7: Driver installation
7.9 Microsoft .NET Framework 3.5 SP1
This section provides the instructions on how to install the Microsoft .NET Framework 3.5
SP1 software on the system.
You need to manually install the Intel
®
Microsoft .NET Framework 3.5 SP1 software on a
Windows operating system.
To install the drivers:
1. Restart the computer, and then log on with Administrator privileges.
2. Insert the motherboard/system support DVD to the optical drive, and nd the utility
menu.
3. Click the item Microsoft .NET Framework 3.5 SP1 software from the menu, and then
follow the onscreen instructions to complete the installation.
