ASUS RS740-E7-RS24-EG
1-3
1.2 Serial number label
Before requesting support from the ASUS Technical Support team, you must take note of the
product’s serial number containing 14 characters such as
xxS0xxxxxxxxxx
as shown in the
gure below. With the correct serial number of the product, ASUS Technical Support team
members can then offer a quicker and satisfying solution to your problems.
xxS0xxxxxxxxxx
RS740-E7-RS24-EG
