Asus rs740-e7/rs24-eg [151/212] To rebuild the drive
![Asus rs740-e7/rs24-eg [151/212] To rebuild the drive](/views2/1214370/page151/bg97.png)
ASUS RS740-E7-RS24-EG
6-17
3. After selecting the drive to rebuild, press <F10>. When prompted, press <Y> to rebuild
the drive.
4. When rebuild is complete, press any key to continue.
SPACE-(De)Select,F10-Start Rebuild,F2-Drive Information,F3-View Virtual Drives
LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010
BIOS Version A.10.09231523R
Port # 1 DISK 77247MB HDS72808PLA380 PF20A60A
Configure
Initialize
Objects
Rebuild
Check Consistency
Management Menu
REBUILD - PHYSICAL DRIVES SELECTION MENU
ONLIN A00-00
FAIL A00-01
0
1
PORT #
Rebuilding of Drive Will Take A Few Minutes. Start Rebuilding Drive (Y/N)?
