Chapter 1: Product introduction
1-2
*ASUS System Web-based Management
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
Model Name RS740-E7-RS24-EG
Chassis ASUS R40B 4U Rackmount Chassis
Motherboard Z9PE-D16-10G/DUAL Server Board
Component
1 x 800W Redundant Power Supply (80 PLUS Platinum)
1 x SAS/SATA Backplane Board
1 x Front I/O Board
1 x Front USB Card
1 x Power Sharing Board
2 x Easy-swap Front System fans (120x38mm)
2 x Easy-swap Rear System fans (80x38mm)
24 x Hot-swap 3.5-inch HDD tray
2 x Hot-swap 2.5-inch HDD tray
Accessories
1 x RS740-E7-RS24-EG User’s Guide
1 x RS740-E7-RS24-EG Support CD
1 x ASWM Enterprise Support CD
*
1 x ASMB6 - iKVM Support DVD
2 x CPU Heatsink
1 x Bag of Screws
- (96 x 3.5-inch HDD tray screws, 8 x 2.5-inch HDD tray screws)
2 x AC Power cables
Optional Items
1 x Tool-less Friction Rail kit
1 x 800W Redundant Power Supply Module (Second)
1 x ASUS PIKE 2108-32PD HW RAID card
1 x ASUS PIKE 2208 8-port HW RAID card
1 x ASUS PIKE 2308 8-port RAID card
