Asus rs740-e7/rs24-eg Инструкция по эксплуатации онлайн [179/212] 177952

ASUS RS740-E7-RS24-EG 7-7

5. When asked if you will load additional RAID controller drivers, select No, then press

<Enter>.

6. Follow the onscreen instructions to nish the OS installation.

7. When the installation is completed, DO NOT click Reboot. Press <Ctrl> + <Alt> + <F2>

to switch to the command-line interface from graphic user interface.

8. Type the following commands when using a Legacy oppy.

mkdir /mnt/driver

mount /dev/fd0 /mnt/driver

cd /mnt/driver

sh replace_ahci.sh

reboot

More Driver Disks?

Yes

Do you wish to load any

more driver disks?
