KARBANTARTÁS
- Az ülés tisztításához csak langyos
szappanos vizet használjon.
- Ha a gyermeküléssel balesetet
szenved vagy az megsérül, a
szaküzlettel ellenőriztesse, hogy
továbbra is használható-e. A sérült
alkatrészeket mindig cserélje le. Ha
nem biztos abban, hogyan kell az új
alkatrészeket felszerelni, kérdezzen a
szaküzlettől.
Tipp! Egy másik konzol használatával
könnyen áthelyezheti az ülést egy
másik kerékpárra.
Sok élménydús kerékpártúrát
kívánunk Önnek és gyermekének a
Hamax gyermekülés használatával!
Minden jót kívánnak a Hamax
munkatársai.
Congratulazioni per l’acquistato del seg-
giolino per biciclette Hamax. Ora ave-
teun seggiolino sicuro e confortevole,
adattabile man mano che il vostro
bambinocresce.
Leggere attentamente le istruzioni pri-
ma di procedere al montaggio o all’uso
del seggiolino.
Conservare accuratamente le pre-
senti istruzioni, vi saranno d’aiuto
se in futuro acquisterete attrezza-
ture per il seggiolino.
INSTALLAZIONE
- Può essere montato su biciclette con
tubo del telaio di diametro compreso tra
28 e 40 mm.
- Non può essere montato su biciclette
con telaio ovale oquadrato.
- Non può essere montato se il porta-
pacchi ha una larghezza superiore a
160 mm.(Si tenga presente che il porta-
pacchi può essere smontatoprima del
montaggio del seggiolino).
- Non può essere montato su biciclette
dotate diammortizzatori.
- Può essere usato su biciclette dotate
diripiani portapacchi.
In caso di dubbi sull’adeguatezzadel
seggiolino, consigliamo di rivolgersial
fornitore della bicicletta per
informazioni.
- Il seggiolino deve essere sempre mon-
tato su una bicicletta adatta a questo
tipo di peso. Rivolgersi al fornitore della
propria bicicletta per informazioni
dettagliate.
- Controllare che le viti dell’attacco siano
benstrette, e ricontrollarle in seguito ad
intervalli regolari.
- Il seggiolino viene sistemato con
l’attacco (6)sul telaio tubolare della
bicicletta. Vedere la fig. F. Leviti di
fissaggio devono essere serrate
beneaffinché il seggiolino sia assicurato
e non si sposti.
Osservare sempre queste istruzioni pri-
ma diusare la bicicletta.
- Per il massimo comfort e la sicurezza
del bambino,assicurarsi che il seggiolino
non scivoli in avanti,in modo che il
bambino non tenda a scivolarne fuori.
Hamax consiglia di fare in modo che lo
schienalesia leggermente reclinato.
- Controllare tutte le parti della bicicletta
per verificare che funzionino corretta-
mente con il seggiolino montato.
UTILIZZO
- Per trasportare il bimbo sulla bicicletta,
il ciclistadeve normalmente avere più di
16 anni. Consultare le leggi ed i regola-
menti del proprio Paesea questo
proposito.
- Il seggiolino è approvato per bambini
conetà compresa tra circa 9 mesi e 6
anni, oppure massimo 22 kg didi peso.
Assicurarsi di controllare di tanto in tan-
toche il peso e le dimensioni del bambi-
nonon superino la capacità massima del
seggiolino.
- Non trasportare bambini troppo piccoli
persedere in modo sicuro sul seggiolino.
Rispettare il limite di età minimo.
Trasportare solo bambini in grado di se-
deresenza aiuto per un periodo di tem-
po prolungato,tanto a lungo quanto pre-
visto per il giro in bici.
- Assicurarsi che non vi sia la possibilità
cheil corpo o gli indumenti del bambino
entrino incontatto con qualsiasi parte
mobile del seggiolino odella bici; e ri-
controllare periodicamente man mano
che il bambino cresce,per via del rischio
di intrappolamento dei piedi tra le ruo-
tee tra i meccanismi dei freni o neiseg-
giolini a molle della bici. Il seggiolino dà
una buona protezione lateralee per i
piedi. Tuttavia, siconsiglia di acquistare
e montare un copricatena/copriruota.
Questi possono essere acquistatipresso
un rivenditore di biciclette.
- Controllare che sulla bicicletta non vi
siano oggettitaglienti o appuntiti, come
dei cavi spezzati, che possano ferire il
bambino.
- Assicurarsi che le cinture di sicurezza
non siano lente opossano intrappolarsi
in parti in movimento,in particolare nel-
le ruote, anche quando siutilizza la bici
senza un bambino seduto sul seggiolino.
- Utilizzare sempre la cintura di
sicurezza,assicurandosi che il bambino
sia ben legato al seggiolino.
- Il bambino seduto sul seggiolino dov-
rebbe indossare vestitipiù pesanti ris-
petto a chi pedala.
- È opportuno proteggere il bambino
dalla pioggia con adeguati indumenti
impermeabili.
- Ricordarsi di mettere il casco al bambi-
noprima di partire in bicicletta.
- Tenere presente che il seggiolino può
diventare molto caldose esposto al sole,
pertanto controllarloprima di posizionar-
vi il bambino.
- Quando si trasporta la bici con la mac-
china (fuoridalla macchina) rimuovere il
seggiolino. Le turbolenze d’aria potreb-
berodanneggiare il seggiolino o allenta-
re i suoi attacchialla bici, e ciò potrebbe
causare incidenti.
Manuale d’usoIT
