Felicitări pentru cumpărarea scaunului
de copil Hamax pentru bicicletă. Acum
aveţi un scaun confortabil şi sigur
pentru copil, care poate fi reglat pentru
a se potrivi copilului dumneavoastră pe
măsură ce acesta creşte.
Vă rugăm să citiţi cu atenţie
instrucţiunile înainte de asamblarea sau
folosirea scaunului pentru copil.
Păstraţi aceste instrucţiuni într-un
loc sigur, deoarece acestea vă vor fi
folositoare dacă, pe viitor, veţi
cumpăra echipamente suplimentare
pentru scaunul copilului.
INSTALARE
- Poate fi montat pe biciclete cu
diametrul ţevii cadrului între 28-40 mm.
- Nu poate fi montat pe biciclete cu
cadru din ţevi ovale sau pătrate.
- Nu poate fi montat acolo unde suportul
pentru bagaje este mai mare de 160 mm.
(Luaţi în considerare faptul că suportul
pentru bagaje poate fi îndepărtat
înainte de montarea scaunului pentru
copil.)
- Nu poate fi montat pe biciclete
echipate cu amortizoare de şoc.
- Poate fi montat pe biciclete cu sau fără
suport pentru bagaje.
Dacă nu sunteţi siguri că scaunul se
potriveşte, vă recomandăm să cereţi
informaţii de la furnizorul bicicletei.
- Scaunul trebuie să fie montat pe o
bicicletă care este adecvată pentru
acest tip de sarcină. Vă rugăm să
solicitaţi informaţii suplimentare de la
furnizorul bicicletei.
- Asiguraţi-vă că şuruburile suportului
sunt bine strânse şi verificaţi-le la
intervale regulate.
- Scaunul pentru copil este montat pe
ţeava cadrului bicicletei cu elementul de
fixare (6). Vezi imaginea F. Şuruburile
trebuie strânse suficient de tare pentru
a fixa scaunul în siguranţă şi pentru a-l
împiedica să alunece.
Faceţi-vă o regulă din a verifica aceasta
înainte de a pleca într-o cursă cu
bicicleta.
- Pentru un confort optim şi pentru
siguranţa copilului asiguraţi-vă că
scaunul nu alunecă în faţă, astfel încât
copilul să nu aibă tendinţa de a aluneca
din scaun.
Hamax recomandă ca spătarul să fie
puţin înclinat în faţă.
- Verificaţi funcţionarea corectă a
tuturor componentelor bicicletei cu
scaunul de bicicletă montat.
UTILIZARE
- Pentru a putea transporta un copil pe
bicicletă, cel care conduce bicicleta
trebuie să aibă vârsta de cel puţin 16
ani. Consultaţi legile şi reglementările
naţionale.
Scaunul este aprobat pentru copii de la
aproximativ 9 luni până la 6 ani sau
până la o greutate maximă de 22 kg.
Asiguraţi-vă că aţi reverificat din când
în când faptul că greutatea şi
dimensiunea copilului nu depăşesc
capacitatea maximă a scaunului.
- Nu transportaţi un copil care este prea
mic ca vârstă pentru a sta în siguranţă
în scaun. Transportaţi numai un copil
care este capabil să stea pe scaun fără
ajutor pentru un interval de timp mai
îndelungat, cel puţin pe toată durata
deplasării cu bicicleta.
- Asiguraţi-vă că nu este posibil ca o
parte a corpului sau a vestimentaţiei
acestuia să intre în contact cu părţile
mobile ale scaunului sau bicicletei şi
verificaţi acest lucru din nou, pe măsură
ce copilul creşte, din cauza pericolului
de prindere a piciorului în roată, în
mecanismele de frânare sau în şaua cu
arcuri. Scaunul copilului oferă o
protecţie bună a părţilor laterale şi a
picioarelor copilului. Oricum,
recomandăm să cumpăraţi şi să
montaţi o protecţie a roţii/lanţului
închisă. Puteţi cumpăra aceasta de la
magazinul de biciclete.
- Verificaţi ca la bicicletă să nu existe
obiecte ascuţite, cum ar fi cabluri rupte,
care pot accidenta copilul.
- Asiguraţi-vă că sistemul de prindere
nu este liber şi că nu poate fi blocat în
componentele mobile, în special ale
roţilor, inclusiv atunci când bicicleta
este utilizată fără un copil în scaun.
- Utilizaţi întotdeauna centura de
prindere/sistemul de siguranţă,
asigurând fixarea copilului în scaun.
- Un copil care stă în scaun trebuie să
fie îmbrăcat mai gros decât biciclistul.
- Copilul trebuie să fie protejat împotriva
ploii printr-o pelerină impermeabilă.
- Nu uitaţi să puneţi casca de protecţie a
copilului înainte de a pleca cu bicicleta.
- Nu uitaţi că scaunul se poate încinge
puternic dacă stă expus la soare, aşa că
verificaţi scaunul înainte de a aşeza
copilul în el.
- La transportarea bicicletei cu maşina
(în exteriorul maşinii) scoateţi centura.
Vântul puternic ar putea deteriora
scaunul sau ar putea slăbi sistemul de
prindere de bicicletă, ceea ce ar putea
cauza un accident.
AVERTISMENTE
- Avertisment: Nu adăugaţi bagaje
suplimentare sau echipamente la
scaunul copilului, deoarece acest lucru
ar putea conduce la depăşirea greutăţii
totale de 22 kg. Recomandăm ca
bagajul suplimentar să fie ataşat de
partea frontală a bicicletei
- Avertisment: Nu modificaţi scaunul
pentru copil. Acest lucru va invalida
automat garanţia şi va anula
răspunderea fabricantului pentru
produs.
- Avertisment: Reţineţi că greutatea
copilului în scaun ar putea să afecteze
stabilitatea bicicletei şi caracteristicile
de manevrare, în special când viraţi şi
frânaţi.
- Avertisment: Nu lăsaţi niciodată
bicicleta parcată cu un copil
nesupravegheat în scaun.
- Avertisment: Nu utilizaţi scaunul dacă
unele dintre componente sunt
deteriorate.
Manualul utilizatoruluiRO
